BQ 5MP Turret Camera



BX-BQ-HCX9201H-2MP, 5 MegaPixel, full colour, high definition turret camera

Parameter Ref:
Dimension (mm)L 122mm ×W 92.5mm × H 13.3mm
Sensor1/2.8” 2.0M Pixel Sony IMX291 CMOS
Shutter1/5 -1/20000 sec
Day & night conversion modeauto ICR filter color to black & white
Dynamic Range100dB
Minimum Illumination0.005Lux@F1.2 colour,0.001Lux@F1.2 black & white
Backlight CompensationOption of selecting area
Digital noisy3D denoise
Camera LensFocus2.8mm、3.6mm、4mm、6mm、8mm
Frame rate50Hz: 25fps (2560 x 1960, 1920 × 1080,1280 × 960,1280 × 720) 60Hz: 30fps (2560 x 1960, 1920 × 1080,1280 × 960,1280 × 720)
ImagesAdustable corridor mode, saturability, brightness, contrast and acutance through client side or brower
Backlight compensationOption of selecting area
Area of interestROI Support dual stream, setting 1 fixed field respectively
Infrared function
Infrared irradiate lengthMaximium 50 meters
Infrared threshold1 line 10/100 BaseT ethernet,RJ45 interface
Network Functions
MemorySupport Micro SD/SDHC/SDXC(128G)offnet lockity memory,NAS(NFS,SMB/CIFS)
Intelligent alarmMotion detection, dynamic analysis, shelter alarming, disconnect network alarm, IP address conflict, storage full, storage fault, cross border detection, district intrude detection
